Aluminium AODD Pumps
Aluminium-bodied AODD pumps — the economical workhorse for paint, oil, coolant and general industrial fluid transfer.
Technical Specifications
| Parameter | Value |
|---|---|
| Size range | 1/4 in to 2 in |
| Max flow | up to 570 LPM |
| Max head | up to 84 m |
| Max solids | up to 6.35 mm |
| Body material | Aluminium alloy (ADC12) |
| Diaphragm | PTFE / Nitrile / Santoprene |
| Connections | NPT / BSPT threaded |
| Max temperature | up to 90°C |
Key Features
- ✅Lightweight — portable and easy to install
- ✅Lowest acquisition cost in the AODD range
- ✅No electricity — air driven, safe for flammable areas
- ✅Self-priming, dry-run safe, handles solids
- ✅Proven in paint and lubrication service for decades
Applications
- Paint transfer and circulation lines
- Oil and lubrication systems
- Coolant and cutting fluid transfer
- Construction dewatering
- General industrial fluid transfer
FAQ
Can an aluminium pump handle solvents?
For paint solvents we recommend PTFE or SS wetted parts; aluminium bodies with PTFE diaphragms work for most paint service.
How long does an aluminium AODD pump last?
With proper maintenance (diaphragm replacement every 6-12 months), pumps run for many years.
Do you supply spare parts for aluminium pumps?
Yes — diaphragms, valve balls, seats and air valve kits are stocked. See our Spare Parts section.
Need a quote?
Send your flow rate, head, media and connection size — we'll confirm model and price within 24 hours.
