Plastic AODD Pumps (PP / PVDF)
Corrosion-resistant polypropylene (PP) and PVDF body options for aggressive chemical transfer — acids, alkalis, plating solutions and water treatment chemicals.
Technical Specifications
| Parameter | Value |
|---|---|
| Size range | 1/4 in to 2 in |
| Max flow | up to 570 LPM |
| Max head | up to 84 m |
| Max solids | up to 6.35 mm |
| Body material | PP / PVDF |
| Diaphragm | PTFE / Santoprene / Neoprene |
| Connections | NPT / BSPT threaded |
| Max temperature | up to 90°C (PP) / 120°C (PVDF) |
Key Features
- ✅Corrosion-resistant wetted path for acids and alkalis
- ✅Self-priming and dry-run safe
- ✅No electricity — air driven, ATEX-safe for hazardous areas
- ✅Built-in filter and anti-drip on misting models
- ✅Low maintenance — simple 4-bolt disassembly
Applications
- Acid & alkali transfer
- Plating and etching lines
- Water & wastewater treatment
- Chemical dosing and batching
- Electroplating baths
FAQ
Can a plastic AODD pump handle sulfuric acid?
PP handles dilute sulfuric; for concentrated acid up to 98% choose PVDF or PTFE wetted parts.
What is the lifespan of a PP pump diaphragm?
With normal chemical service, 6-12 months; PTFE diaphragms last longer in aggressive media.
Do you offer PVDF pumps for solvent transfer?
Yes — PVDF handles most solvents, halogens and strong oxidizers.
Need a quote?
Send your flow rate, head, media and connection size — we'll confirm model and price within 24 hours.
